Kołnierz żeliwny pokryty PP FOX
- zastosowanie: woda i gaz
- pokrycie: PP wzmacniany włóknem szklanym
- Do tulei PE
- Odporne na korozje
- Wkład z żeliwa GGG
Wymiary
| Kod produktu | D2 (mm) | D1 (mm) | OD (mm) | ID (mm) | B (mm) | K (mm) | L3 (mm) | Otwory | Ciśnienie (bar) | Waga (kg) |
| KPP020015.IP | 15 | 20 | 106 | 28 | 14 | 65 | 18 | 4 | 10/16 | 0,4 |
| KPP025020.IP | 20 | 25 | 118 | 34 | 14 | 75 | 18 | 4 | 10/16 | 0,4 |
| KPP032025.IP | 25 | 32 | 122 | 42 | 14 | 85 | 17 | 4 | 10/16 | 0,4 |
| KPP040032.IP | 32 | 40 | 142 | 51 | 18 | 100 | 17 | 4 | 10/16 | 0,5 |
| KPP050040.IP | 40 | 50 | 156 | 62 | 18 | 110 | 19 | 4 | 10/16 | 0,7 |
| KPP063050.IP | 50 | 63 | 171 | 78 | 18 | 125 | 20 | 4 | 10/16 | 0,9 |
| KPP075065.IP | 65 | 75 | 191 | 92 | 18 | 145 | 21 | 4 | 10/16 | 1,00 |
| KPP090080.IP | 80 | 90 | 206 | 108 | 18 | 160 | 21 | 8 | 10/16 | 1,1 |
| KPP110100.IP | 100 | 110 | 226 | 128 | 18 | 180 | 22 | 8 | 10/16 | 1,5 |
| KPP125100.IP | 100 | 125 | 226 | 135 | 18 | 180 | 23 | 8 | 10/16 | 1,4 |
| KPP140125.IP | 125 | 140 | 261 | 158 | 18 | 210 | 25 | 8 | 10/16 | 1,7 |
| KPP160150.IP | 150 | 160 | 296 | 178 | 22 | 240 | 28 | 8 | 10/16 | 1,8 |
| KPP180150.IP | 150 | 180 | 296 | 188 | 22 | 240 | 27 | 8 | 10/16 | 1,9 |
| KPP20020010.IP | 200 | 200 | 350 | 235 | 22 | 295 | 32 | 8 | 10 | 3,1 |
| KPP22520010.IP | 200 | 225 | 350 | 238 | 22 | 295 | 31 | 8 | 10 | 3,1 |
| KPP25025010.IP | 200 | 250 | 412 | 288 | 22 | 350 | 36 | 12 | 10 | 4,9 |
| KPP28025010.IP | 250 | 280 | 412 | 294 | 22 | 350 | 35 | 12 | 10 | 4,4 |
| KPP31530010.IP | 300 | 315 | 462 | 338 | 22 | 400 | 42 | 12 | 10 | 6,4 |
| KPP35535010.IP | 350 | 355 | 525 | 376 | 22 | 460 | 52 | 16 | 10 | 11,10 |
| KPP40040010.IP | 400 | 400 | 586 | 430 | 26 | 515 | 56 | 16 | 10 | 14,7 |
| KPP45050010.IP | 500 | 450 | 690 | 514 | 27 | 620 | 54,5 | 20 | 10 | 20,30 |
| KPP50050010.IP | 500 | 500 | 690 | 530 | 27 | 620 | 55 | 20 | 10 | 19,20 |
| KPP56060010.IP | 600 | 560 | 804 | 615 | 30 | 725 | 62 | 20 | 10 | 30 |
| KPP63060010.IP | 600 | 630 | 804 | 642 | 30 | 725 | 62 | 20 | 10 | 27,7 |
