Electrode steam generator for sauna...

Electrode steam generator for sauna ELMC 5 with a capacity of 5KG/H 230V DEVATEC

wysyłka 24h
Darmowa wysyłka
Tax included



ELMC 5 steam generator

ELMC sauna steam generators are a series of efficient and economical devices. We offer devices with a capacity from 5 to 40 kg pay per hour. ELMC steam generators are a guarantee of precise maintenance of humidity. Steam is sterile, clean and free from contamination. Optimized water intake as well as demountable steam cylinders, ensure low operating costs

Generator pary ELMC
Generator pary ELMC

Operating principle

The flow of electric current through electrodes immersed in water produces sterile, clean and odorless steam, which, due to the overpressure created in the cylinder, is pumped into the distribution element (steam lance). Steam generation in the device is carried out in a fully automated manner. The appropriate electrical conductivity of the water in the cylinder, which determines the correct functioning of the device, is maintained automatically due to cyclic flushing of the cylinder with tap water. The frequency of this process is regulated by an electronic system. As a result, the working time of the cylinders is significantly extended.

The generator produces the necessary amount of steam until the measured air temperature reaches the required level. The steam production process is resumed when the sensor detects a drop in air temperature below the set level.


  • capacity 5 kg/h
  • demountable cylinder
  • Supply voltage - 230 V / Control voltage - 230 V
  • Steam connection - D 25 mm
  • Pnom=3,75 kW / Pmaxi=4,05 kW / Inom=16,3 A / Imaxi=17,6 A
  • system "Antifoaming" system to extend the life of the cylinders
  • Excellent service access to the machine
  • demountable cylinders as standard
  • large diameter drain valve with self-cleaning system
  • lances for steam distribution in the room
  • easy installation
Generator pary ELMC
Generator pary ELMC


The warranty period is 24 months. The warranty does not cover defects resulting from failure to follow the instructions for installation, use or maintenance work. The warranty does not cover consumable components (gaskets, cylinders, etc.).

Need help?

If you have not found the answer to your inquiry, please use the form below and write how we can help you?. We provide quick contact and comprehensive service.

Team Poolsystem.pl
Tomasz Tomkowicz

Pool Technology Specialist

Thank you for reading our article, if you have more questions or need more specialized help - write to me using the form.

Product Details

Power supply
230V - 1 phase
