About Fairland Inverter-Plus Pumps

Fairland Inverter-Plus IPHCR are pool heat pumps with full inverter technology. They are more expensive than conventional heat pumps, but are definitely more energy efficient, as the inverters used smoothly adjust the output (i.e. revolutions) of both the compressor and the fan to achieve the user's desired pool water temperature. These pumps are designed to operate mainly at average efficiencies of 50%, which is completely sufficient to maintain the desired water temperature throughout the swimming season. When deciding to purchase an Inverter-Plus pump, we suggest choosing a larger model so that the heat pump will run most of the time, but at a lower speed. Such operation makes it possible to achieve a high cooling coefficient of performance (COP), 10 times lower noise levels, prolongs the life of the pump due to less intensive operation, and ensures at least half the operating costs compared to On/Off pumps.

TUV Rheinland Certification

Fairland pool heat pumps are certified after testing by the German certification body TUV Rheinland and fully comply with EU regulations given in EN14511.

Schemat Pompy Ciepła

Operating principle of Inverter-Plus IPHCR heat pumps

Inverter-Plus are air pool pumps, or more precisely, air-to-water pumps, and use atmospheric air as the lower source (from which heat is extracted). These pumps are "monoblock" pumps, i.e. compact pumps that contain all components in a single housing. This makes the installation of the pumps very simple, and the additional investment costs are the purchase of PVC pipes, fittings, valves and connecting the device to the pool filtration system.

Low flow resistance in the condenser, or titanium heat exchanger, in which the pool water is heated, makes it possible to use the existing pool filter pump.

Average COP

Average COP = 11.5 during the 180-day bathing season, assuming A26 C/W26 C/H80 %.

For the On/Off pump, the coefficient remains constant at COP = 5.0 during the entire 180-day period, while for the Inverter-Plus pump, after 5 days of water heating (the beginning of the season), the coefficient reaches an average COP = 11.5.

Average COP = 7.0 during the 180-day bathing season, assuming A15 C/W26 C/H70 %.

For the On/Off pump, the coefficient remains constant at COP = 4.0 throughout the 180-day period, while for the Inverter-Plus pump, after 5 days of water heating (beginning of the season), the coefficient reaches an average COP = 7.0.

Współczynnik COP
Niski Poziom Głośności

Low volume, quiet operation

Inverter-Plus pool pumps use quiet Mitsubishi compressors and inverter fans.

The operation of the device when maintaining the set water temperature at 50% efficiency is about 10 times quieter than the operation of classic On/Off heat pumps.

Easy control, Wifi module

Each Inverter-Plus pump is equipped with a Wifi module, so we can control the operation and temperature using a smartphone.

Operation of Inverter-Plus pumps is very simple. On the housing of the pump is installed a controller with an on/off switch, buttons for setting the water temperature, a Mode and Lock settings button, and a display that shows the inlet/outlet water temperature, pump output and the selected mode of operation.

Operation of the unit comes down to turning on the pump and using the buttons to select the desired pool water temperature. Using the Mode button, you can select the standard Smart mode or the Silence mode. It is recommended to select Silence mode at the beginning of the swimming season, when the water temperature has not yet reached the setpoint.

Sterowanie za Pomocą Modułu WiFi
Dobór Pomp Ciepła

Which heat pump Inverter-Plus model for a swimming pool?

Selection of the appropriate Inverter-Plus IPHCR heat pump is made on the basis of the volume of the pool, according to the indications in the table "Technical data".

For example, for a pool with a volume of 43 m3 according to the table "Technical data", the appropriate pumps are IPHCR33 and IPHCR45.

However, the manufacturer recommends that you always choose a larger pump model (in the example above it would be IPHCR45). This will allow the pump to work longer at a lower speed (capacity) bringing the following benefits:

  • significantly higher COP, thereby providing at least half the
  • The cost of heating a swimming pool compared to on/off pumps,
  • faster heating of water,
  • 10 times lower noise level,
  • longer pump life due to less intensive operation.

5 years warranty

The product is backed by an impressive 5-year manufacturer's warranty, demonstrating confidence in the quality and durability of the product. In the event of any faults or problems with its functioning, the manufacturer provides a free repair service.

The Door to Door service will ensure that you don't have to move from your home. We will collect the pump ourselves and send it straight back to your home after service.

Technical specifications of Fairland Inverter-Plus heat pumps

ModelIPHCR15

IPHCR20

IPHCR26

IPHCR33

IPHCR45IPHCR55IPHCR70TIPHCR100T
Recommended volume of the pool (m3)15 - 3020 - 4025 – 4530 – 5540 - 7550 - 9565 - 12090 - 170
Air temperature range (0C)from -7 to 43
Parameters at A26 C/W26 C/H80% - air temp/water temp/humidity
Heating power (kW)6,58,510,513,017,520,527,3 35,8
COP - coefficient of performance14,7 – 6,014,8 – 7,415,0 – 7,415,4 – 7,315,8 – 6,215,3 – 6,015,3 – 6,5 15,6 – 5,8
COP - at 50% efficiency
10,510,911,011,011,110,711,210,9
Parameters at A15 C/W26 C/H70% - air temp/water temp/humidity
Heating power (kW)4,86,37,39,011,514,018,024,5
COP - coefficient of performance7,3 – 4,57,4 – 5,07,7 – 4,87,7 – 4,87,8 – 4,57,7 – 4,48,1 – 4,8 8,0 – 4,7
COP - at 50% efficiency
6,36,66,86,86,46,36,87,0

Parameters at A35 C/W28 C/H80% - air temp/water temp/humidity
Cooling power (kW)3,04,04,65,67,810,012,2 16,5
Noise level at 1 m dB(A) distance37,8 - 47,238,8 - 48,238,6 - 49,942,1 - 50,743,1 - 53,840,9 - 54,243,5 – 54,942,6 - 54,7
Compressor

Mitsubishi DC twin rotor rotary inverter

Fan motor

Brushless DC inverter

Heat exchanger (condenser)Spiral titanium covered with PVC
Housing materialAluminum alloy
Power supply230 V/50 Hz230 V/50 Hz230 V/50 Hz230 V/50 Hz230 V/50 Hz230 V/50 Hz400 V/50 Hz400 V/50 Hz
Rated power at 15 deg C0,13-1,06kW0,17-1,20kW0,19-1,50kW0,23-1,81kW0,30-2,60kW0,36-3,18kW0,55-3,9 0,61-5,20kW
WiFiIncluded
Fuse (A)9,010,512,014,518,021,09,012,0
Power cable (mm2)3x1,53x2,53x2,53x2,53x43x45x2,55x2,5
Recommended water flow (m3/h)2–42-43-44-66,5-8,58-1010 – 1212-19
Złączki wejścia/wyjścia wody basenowejd50
RefrigerantR32
Net dimensions - L - H - W (mm)894x359x648894x359x648894x359x648954x359x648954x429x648954x429x7551084x429x9481154x539x948
Net weight (kg)42454950636893120
Warranty

5 years

Package contents

Pompa Ciepła Fairland

Heat Pump Fairland Inverter Plus

Przykrycie na Zimę

Winter cover

Wibroizolatory

Vibroisolators

Moduł WiFi

Built-in WiFi module

Instrukcja Obsługi

Instruction

Dimensions

ABCDEFGH
514 mm790 mm498 mm539 mm1154mm650 mm74 mm948 mm

Main features of Fairland Inverter-Plus:

Certification by TUV Rheinland

Inverter Plus pumps are certified after testing by the German certification body TUV Rheinland and fully comply with EU regulations given in the EN14511 standard.

Low operating costs

The average efficiency coefficient of Inverter-Plus pumps is COP = 11.5 (50% efficiency) and COP = 16 (20% efficiency) assuming A260C/W260C/H80%. Classic On/Off heat pumps achieve an efficiency factor of COP = 5.0 under these conditions - that is, more than 2 times lower.

Operating at air temps down to - 7 C

Inverter-Plus heat pumps are designed to operate at air temperatures as low as -7 C. This significantly extends the ability to enjoy comfortable pool water temperatures at low air temperatures.

Mitsubishi inverter compressor

The Inverter-Plus pumps use Mitsubishi's DC twin rotor compressors, known for their high quality. They ensure high efficiency, quiet operation and long service life.

Inwerterowy silnik elektryczny wentylatora

Inverter-Plus pumps use brushless DC inverter motors. This ensures lower power consumption and generates significantly less noise.

Wifi control

Inverter-Plus pumps have a built-in WiFi module as standard, allowing remote management from anywhere at any time via an app

Need help?

If you have not found the answer to your inquiry, please use the form below and write how we can help you?. We provide quick contact and comprehensive service.

Team Poolsystem.pl
Tomasz Tomkowicz

Pool Technology Specialist

Thank you for reading our article, if you have more questions or need more specialized help - write to me using the form.

Product Details

Pool size
up to 170 m3
Power
38 kW
Heat pump type
inverter pump
Power supply
400V - 3 phases

About Fairland

Firma Fairland oferuje do sprzedaży basenowe pompy ciepła Comfortline Inverter z częściową technologią inwerterową zastępując nią klasyczne pompy typu włącz/wyłącz. W ofercie znajdziemy również pompy z pełną technologią inwerterową Inverter-Plus

Wszystkie modele  pomp przeszły badania wykonane przez niemiecką instytucję certyfikującą TUV Rheinland. Dzięki temu pompy te w pełni odpowiadają odpowiednim przepisom UE, a podawane w kartach katalogowych parametry są w pełni wiarygodne.
