We will make the bypass to the heat pump for your pool !
When buying a heat pump from our store, add one of the bypasses below to your cart and we will glue it together especially for you and send it with your order - this will make the installation much easier !
*service only valid when pool heat pump is included in the order
FULL INVERTER TEBAS pool heat pump
TEBAS Full Inverter heat pump with factory-installed Wi-Fi module and winter cover free of charge, is equipped with a number of components and sensors to ensure efficient and trouble-free operation. The water connection with a diameter of 50 mm should be made using a bypass.
The unique full DC inverter technology used makes the efficient two-speed compressor and brushless fan motor perfectly change speed. This makes the Tebas Full Inverter model CP heat pumps achieve an exceptionally high COP.
Only FULL Inverter technology results in stepless operation of the entire system and ensures the most comfortable and quiet operation. In tests, all components of the unit were checked and optimized performance was achieved.
Working Modes suit for your requirements
The Tebas Full Inverter heat pump operates in 3 modes:
Smart mode - the best balance between efficiency and performance.
Silent mode - provides the user of the pool, extremely quiet operation.
Power mode - heating time in a much shorter period of time.
All modes can be set to 3 modes of operation: automatic (RECOMMENDED), heating, cooling.
About Tebas pool heat pumps
TEBAS heat pumps are manufactured using high-quality materials and materials under the supervision of a Polish company. They are designed to reduce energy consumption by generating heat using energy from the surrounding air.
It is one of the best and cheapest solutions for heating pool water in European climatic conditions using "green energy".
The characteristics of these pumps are high COP and maximum heat gain at low temperatures (higher COP at low temperatures).
The concept of COP (Coefficient of Performance) cooling efficiency requires explanation. This is the ratio of the heating power output to the power consumed by the pump. For example, if the COP is 8, and the pump draws 1 kW of power, it gives up 8 times the heating power, or 8 kW.
Principle of TEBAS heat pumps
TEBAS pumps are air pumps, or more precisely, air/water pumps, and use atmospheric air as the lower source (from which heat is extracted).
These pumps are pumps that contain all components in a single housing. This makes the installation of the pumps very simple, and the additional investment costs are the purchase of PVC mm pipes, fittings and valves and the connection of the device to the pool filtration system.
The low flow resistance of the condenser, or titanium heat exchanger, in which the pool water is heated, makes it possible to use the existing pool filter pump.
Which model of tebas heat pump for my pool?
The selection of the appropriate TEBAS heat pump is made on the basis of the volume of the pool, according to the indications in the table "Technical data".
However, it is recommended to always select a larger pump model. This will ensure that the pump will work longer bringing the following benefits:
- faster heating of water,
- longer pump life due to less intensive operation.
Dimensions
A | B | C | D | E | F |
1030 | 320 | 730 | 700 | 105 | 390 |
Technical data of TEBAS heat pumps
Type | Manufacturer code | Recommended pool volume (m3) | Heating power (kW) P26/W26 | COP | Heating power (kW) | COP | Flow rate (m3/h) | Power supply (V/Ph/Hz) | Refrigerant | Water connection | Dimensions L/W/H (mm) | Noise level at 1m distance (dB) | Noise level at 10m (dB) |
11,0 kW | 14608inver | 30 - 50 | 11 -2,6 | 7,1 - 15 | 7,8 - 2,1 | 5,5 - 8,2 | 5 | 230 V/1/50 | R32 | d50 | 880x320x560 | 39 - 49 | 19 - 29 |
13,0 kW | 14610inver | 40 - 60 | 13 - 3,1 | 7,2 - 15,1 | 9,2 - 2,5 | 5,5 - 8,2 | 6 | 230 V/1/50 | R32 | d50 | 930x350x665 | 40 - 50 | 20 - 30 |
17,5 kW | 14613inver | 50 - 70 | 17,6 - 4,4 | 7,2 - 15,1 | 12 - 3,4 | 5,5 - 8,2 | 8 | 230 V/1/50 | R32 | d50 | 1030x360x715 | 42 - 52 | 22 - 32 |
26,0 kW | 14615inver | 75 - 95 | 26 - 6,3 | 7 - 14,7 | 18,8 - 5 | 5,2 - 7,9 | 10 | 400 V/3/50 | R32 | d50 | 1070x490x1090 | 45 - 55 | 25 - 35 |
32,0 kW | 14617inver | 90 - 110 | 32 - 8 | 7,2 - 15,1 | 23 - 59 | 5,3 - 8 | 11 | 400 V/3/50 | R32 | d50 | 1070x430x1245 | 45 - 55 | 26 - 36 |
37,0 kW | 14619inver | 110 - 130 | 37 - 9,2 | 7,1 - 15,0 | 27 - 6,8 | 5,4 - 8.2 | 13 | 400 V/3/50 | R32 | d50 | 1120x430x1295 | 49 - 59 | 28 - 39 |
The main features of TEBAS heat pumps:
Auto Mode Function
Automatic switching to heating or cooling mode
High COP
Higher energy gain, thus lower energy costs
Complete set of sensors
Flow, pressure, water and air temperature sensor
Titanium heat exchanger
The heat exchanger is made of double titanium coils
