ASTRAL POOL LYRIOX UV-C pool lamp
A solution to suit the needs of most pools & spas. 100% made of PVC, Lyriox UV-C is corrosion free, hence fully compatible with salt water High quality UV lamp with 9 000 h lifespan
UV technology used by Lyriox UV-C is a safe, eco-friendly and very efficient disinfection method Drastically reduces the use of residual disinfection products (chlorine, active oxygen...) Adapted to all pool & spa types, finishes and water treatments
A range of compact products to be easily integrated in the pool pad. Easy to install on a bypass thanks to its shape & provided unions (50 or 63mm depending on sku
available from 15W up to 110W).Specific 50W Compact model with a U-shape design for an even easier installation
Installation Diagram
The UV lamp must always be installed in the technical room, connected in accordance with pool installations (behind the filter, pump, etc.) It is advisable to install the lamp in a place where the filament can be quickly accessed. This will enable maintenance to be carried out without having to partially or completely empty the pool. If the lamp is installed on a "by-pass" (recommended), a valve should be installed to regulate the flow.
Technical data
Lyriox UV-C 15W | Lyriox UV-C 25W | Lyriox UV-C 30W | Lyriox UV-C 50W Compact | Lyriox UV-C 55W | Lyriox UV-C 75W | Lyriox UV-C 110W | |
Input voltage | 220-240V / 50-60 Hz | ||||||
Consumption | 19 W | 21 W | 38 W | 42 W | 49 W | 63 W | 93 W |
Wiring | Slaved to filter pump | ||||||
Optimal flow | 2 m3/h | 2 m3/h | 4 m3/h | 5 m3/h | 8 m3/h | 10 m3/h | 15 m3/h |
Max flow rate | 7,5 m3/h | 10 m3/h | 15 m3/h | 16 m3/h | 20 m3/h | 25 m3/h | 25 m3/h |
Max pool volume | 15 m3 | 25 m3 | 30 m3 | 50 m3 | 55 m3 | 75 m3 | 110 m3 |
UV power | 15 W | 25 W | 30 W | 50 W | 55 W | 75 W | 110 W |
UV lamp type | 1 x T8 | 1 x T8 | 1 x T8 | 2 x T8 | 1 x T8 | 1 x T8 | 2 x T8 |
UV lamp hours | approx. 9,000 hours | ||||||
UV chamber material | PVC | ||||||
Max working pressure | 2,5 bar | ||||||
Working temperature | 2 - 40 ℃ | ||||||
Ballast casting | Integrated, PVC, fully sealed | ||||||
Protection rating | IPX5 | ||||||
Connection Inlet-Outlet | 50 mm | 63 mm | |||||
Warranty | 24 months |
Contents of the package
- uv lamp
- lamp filament
- uv lamp power supply unit
- seals
Dimensions
