PCP150
6,599.00 zł
Secure Payments
wysyłka 24h
Odbiór osobisty w siedzibie
Odbiór osobisty w siedzibie
ul. Graniczna 59, Chorzów, Poland
Free!
Przesyłka paletowa
Przesyłka paletowa
Pallet transport | Add 3-5 days
Free!

Professional consultantsPool technology specialists
Door 2 Door serviceWe take care of all the paperwork
100% Polish warrantyEasy and fast procedure
Authorised dealerYou are buying first hand

Description

We will glue the bypass to the heat pump for your pool !

When buying a heat pump from our shop, add one of the bypasses below to your basket and we will glue it together especially for you and send it with your order - this will make installation much easier!

*valid only when pool heat pump is included in the order

POOLSYSTEM PCP inverter pool heat pump

A heat pump is the best solution for heating pool water. It is an extremely efficient and environmentally friendly device that will ensure comfortable swimming conditions throughout the season, and extend the season by several months

A pool heat pump is a system that uses heat energy from the environment to heat the water in your pool. Its operation is based on the principle of converting heat energy from one medium to another using a small amount of electricity. As a result, even on colder days, the heat pump is able to heat the water efficiently, keeping it at the optimum temperature for swimming.

Pompa ciepła PCP POOLSYSTEM
Pompa ciepła PCP POOLSYSTEM

Enjoy always hot water and low bills

Nowadays, with the search for green and efficient solutions becoming increasingly important, the pool heat pump stands out as a sustainable device that allows you to enjoy swimming in your pool for a longer period of time, while minimising the impact on the environment and your electricity bill.

One of the key benefits of a PCP pool heat pump is their high efficiency. Through the use of modern technology, heat pumps are able to make efficient use of the available heat energy, resulting in lower running costs compared to traditional water heating systems.

Main features

High COP

Allows efficient operation of the PCP pump

Fast heating time

High efficiency translates into shorter working hours

Silent operation

The use of an inverter allows for noise-free operation

Refrigerant R32

Low environmental impact

Galvanised steel housing

Easy to clean, corrosion-resistant

Built-in WiFi module

Access to parameters from anywhere in the world

Touchscreen heat pump controller

Poolsystem PCP inverter pool heat pumps are equipped with a touchscreen controller.  This is an intuitive and advanced tool that provides users with easy control of the unit.

It allows users to adjust the water temperature, set the operating schedule or monitor the unit's performance. The heat pump touchscreen controller is the perfect combination of convenience and functionality that makes using the heat pump a real pleasure.

Pompa ciepła PCP POOLSYSTEM
Pompa ciepła PCP POOLSYSTEM

Savings from heat pump heating

The electricity consumption of a heat pump heating pool water will be on average 5-6 times lower compared to an electric heater. With a pool heat pump COP efficiency of 6, only 1 kWh of electricity is consumed to generate 6 kWh of heat. For an average sized swimming pool with a capacity of 20 m³, we need to supply around 900 kWh of heat energy per summer month to maintain the required pool water temperature.

Connection of a swimming pool heat pump

In a hydronic system, the heat pump must be located between the filter and any pool water treatment unit. In addition, it must be connected on a bypass to regulate the flow through the heat pump. The water flow rate through the pool heat pump is regulated by a valve at the inlet to the unit and a valve on the bypass. The bypass valves are mandatory and serve to disconnect the heat pump from the system for cleaning the filter system and to drain the heat pump of water for the winter period.

In order to ensure optimum water flow through the heat pump, the valve (1) and the valves (2) must be operated until the water temperature increase (after passing through the heat pump exchanger) reaches 3°C (T inlet-inlet = ~3). The water inlet and outlet temperatures are shown on the unit display.

Pompa ciepła PCP POOLSYSTEM
Pompa ciepła PCP POOLSYSTEM

Control via the Smart Life app

All Poolsystem PCP pool heat pumps are equipped with a WI-FI module so that various parameters can be changed and controlled remotely, including

  • ON/OFF
  • setting the pool water temperature
  • information about the current operating mode of the heat pump
  • setting of the pump operating time
Aplikacja pompy ciepła PCP
Aplikacja POOLSYSTEM PCP
Aplikacja POOLSYSTEM PCP

Four-year warranty on heat pump

The POOLSYSTEM PCP pool heat pump comes with an extended warranty of up to 4 years. This covers any malfunctions or problems with the unit during this period. Our Door to Door service ensures that you don't have to leave your home. We will collect the pump ourselves, carry out the necessary repairs and send it straight back to your home after service. So you can rest assured that even if you have any problems with our product, the repair process will be quick, hassle-free and comprehensive.

Pompa ciepła PCP POOLSYSTEM
Pompa ciepła PCP POOLSYSTEM

Technical data for POOLSYSTEM PCP pool heat pumps

ModelPCP70PCP90PCP110PCP150PCP180

Pool size

15-30 m320-40 m325-50 m330-60 m335-70 m3

Air temp:
Water temp:

(DB/WB) 27°C/24.3°C;
INLET 26°C/ OUTLET 28°C.
Heating power1,5~7,21 kW1,~9,48 kW2,8~11,41 kW3,48~15,3 kW4,34~18,1 kW
Power consumption0.09~1.09 kW0.11~1.44 kW0.17~1.74 kW0.22~2.35 kW0.27~2.81 kW
COP16.7~6.616.4~6.616.5~6.615.9~6.516.1~6.4
Air temp:
Water temp:
(DB/WB) 15°C/12°C;
INLET: 26°C.
Heating power1.3~5.42 kW1.51~7.89 kW2.2~8.21 kW2.96~11.14 kW3.44~13.35 kW
Power consumption0.16~1.06 kW0.18~1.52 kW0.27~1.61 kW0.36~2.19 kW0.41~2.61 kW
COP8.1~5.18.3~5.28.1~5.18.3~5.18.3~5.1
Max. intensity7.32 A7.96 A10.5 A14.5 A17.7 A
Recommended flow rate3.1 m3/h4.1 m3/h4.9 m3/h6.6 m3/h7.7 m3/h
Operating noise32~45 dB(A)33~47 dB(A)33~47 dB(A)34~48 dB(A)34~48 dB(A)
Net weight35 kg37 kg42 kg46 kg46 kg
Net dimension910 x 355 x 620 mm1000 x 400 x 660
Power supply230V / 50 hZ
RefrigerantR32
Operating temperature-10~43 °C
CompressorMITSUBISHI ELECTRIC
Heat exchangertitanium
Water connectionINLET: 50 mm / OUTLET: 50mm
Warranty4 years4 years4  years4 years4 years

Dimensions of the POOLSYSTEM PCP 15 kW heat pump

Wymiary pompy ciepła POOLSYSTEM PCP

Packaging content

POOLSYSTEM PCP

Heat pump POOLSYSTEM PCP

POOLSYSTEM PCP

Drain hose

POOLSYSTEM PCP

Vibration isolators

POOLSYSTEM PCP

Manual

Need help?

If you have not found the answer to your inquiry, please use the form below and write how we can help you?. We provide quick contact and comprehensive service.

Team Poolsystem.pl
Tomasz Tomkowicz

Pool Technology Specialist

Thank you for reading our article, if you have more questions or need more specialized help - write to me using the form.

Product Details

Pool size
up to 60 m3
Power
15 kW
Heat pump type
inverter pump
Power supply
230V - 1 phase
